14 Head Salad Weigher For Weighing Large Volume Products With 5L
Hopper
The salad weigher is a small pattern chute with an angle of 60
degrees, which is beneficial to the falling of materials and
effectively controls the phenomenon of sticking. It is suitable for
the quantitative weighing of vegetable salads, fruit salads,
potatoes, onions, tomatoes, and other fruits and vegetables. The 5L
hopper capacity can weigh more materials, reduce the number of
feedings, and improve efficiency.
Features
1.Special load cell with high precision and high standard.
2. Program recovery function can reduce operation failures, support
multi-segment weight calibration.
3.No products auto pause function can improve weighing stability
and accuracy.
4. Linear amplitude can be adjusted independently, which can make
the feeding more uniform.
5.15 languages available for global markets.
6.100 program capacity can meet the various weighing requirements,
a user-friendly help menu in touch screen contributes to easy
operation.
Mechanical character
1. Speed adjustable rotary top cone is suitable for different
product feeding.
2. The enhanced linear vibrator improves the flowability of the
material.
3. The declinational special linear vibrator pan, ensure smooth
feeding.
4. 60° dimple discharge chute contributes to less sticky problems.
5. The whole cast aluminum thickening machine case enhanced the
strength of the machine, and shorten sample stable time.
6. Optional weighing type material detection, accurate control of
feeding time, material thickness, to ensure the accuracy of the
weighing.
Technical specification
| Model | JW-AM10 | JW-AM14 |
| Identify Code | AM10-1-11 | AM14-1-11 |
| Weighing Range | 100-3000g | 100-3000g |
| Accuracy | X(1) | X(1) |
| Max Speed | 50P/M | 80P/M |
| Hopper Volume | 5L |
| Control Panel | 7” Touch Screen |
| Options | Timing Hopper/Printer/Reject Device |
| Driving System | Step Motor |
| Power Requirement | 220V/1500W/50/60Hz/10A | 220V/1500W/50/60Hz/12A |
| Packing Dimension(mm) | 1910(L)x1290(W)x1810(H) | 2195(L)x1380(W)x2060(H) |
| Gross Weight | 700kg | 850kg |
Application
It is suitable for weighing large volume products such as potatoes,
tomatoes, onions, fruits, vegetables, and salad with a large target
weight.
FAQ
Q1: How to know which packing machine is suitable for us?
You can first tell business representatives which equipment you
want to know, what material is the product, how many grams to
weigh, and the range of accuracy and speed requirements. Our
engineers then recommend suitable packaging machines based on these
data and product characteristics.
Q2: How to operate it?
Many languages are available for global markets. There are not only
detailed instructions but also machine videos for reference
learning.
Q3: Why we should choose your company?
We have many years of industrial production and management
experience, professional R & D, sales, after-sales team. It can
perfectly solve all the problems that customers encounter from
purchase to sale.
Q4: How to cooperate with you?
You only need to contact our business representative, and they will
be patient to guide you through the whole process.
Q5: What's your payment way?
T/T by our bank account directly.
Q6: How about the delivery and after-sales service?
All our machines are tailor-made because different clients have
different requirements, delivery will be within 20 days for the
small multi-head weigher, For the large-scale machine, it takes
longer. Warranty:2years(Electric accessories) and free lifetime
maintenance.
If you got any problem when using the machine and the videos can
not help, our technician will have video chatting with you to fix
your problem
